Allied Telesyn

AT-VIEW PLUS

DEVICE MANAGEMENT

Utilization

Displays the port's utilization information.

Displays port statistics such as the number of frames received and transmitted on the port,
bytes received and transmitted on the port, and port status.

ware version (AT-S63 v1.0.0 NE) supports atiStackSwitch.mib

v2.9. However, AT-View Plus Device Manager supports atiStackSwitch.mib v2.10. As a
result, Port HOL Blocking and Port Admin State, which are parameters defined in v2.9
but not in v2.10, will appear as the Port HOL Limit and the Port STP State parameters
respectively.

Spanning Tree Info

Interface Info

Note

- Valid MIB Set values for the Administration Status parameter are 'up' and 'down'.

Attempting to set this parameter to any other value will result in the error message: "The
error occurred with 'Set' operation. Error: bad value."

Error Statistics

Displays error statistics.

Detail Info

Displays detailed port information such as duplex mode.

Note

- Setting the Port MDIO parameter to 'auto mdix' will cause the parameter to be set

to 'mdi'.

Note

- The current firm

Note

- The current firmware version does not allow the Port Back Pressure Limit

parameter to be configured.

Note

- Valid MIB Set values for the Port Flow Control parameter are 'disable' and

'enable'. Attempting to set Port Flow Control to 'unknown' will cause the parameter to be
set to 'enable'.

Note

- Valid MIB Set values for the Port Back Pressure parameter are 'disable' and

'enable'. Attempting to set Port Back Pressure to 'unknown' will cause the parameter to be
set to 'enable'.

Note

- The Port State and Port CoS/QoS Priority parameters are not applicable to the AT-

9400 series and should be ignored.

Displays the port's spanning tree parameters.

CoS

Displays Class of Service parameters and allows you to configure CoS for a port, change
the default mappings of CoS priorites to egress priority queues and configure a
scheduling method for Class of Service.
