Allied Telesis AT-VIEW PLUS 3.2 DEVICE MANAGEMENT User Manual
Page 289
Allied Telesyn
AT-VIEW PLUS
DEVICE MANAGEMENT
Device Manager LEDs for AT-AR041 and AT-AR042
LED
State
Description
Data LEDs Orange
Gray
For permanent circuits, HDLC packets are being exchanged
between the switch or router and another TE end system device
(normally another switch or router) over the respective B-
channel. For on-demand ISDN, there is a call up over the
respective B-channel.
No packet/data transmission over B-channel.
Network Service Modules
PN 613-50665-00 Rev C
Page 289 of 294
