Allied Telesyn AT-VIEW PLUS
DEVICE MANAGEMENT
Device Manager LEDs for AT-8500 Series
LED State Description
PWR Green The switch is receiving power.
MASTER Orange
Gray
The switch is the master switch of an enhanced stack.
The switch is a slave switch or is not a member of an enhanced
stack.
DUPLEX Green
Orange
The port is operating in full-duplex mode.
The port is operating in half-duplex mode.
Note - Please refer to Uplink Modules for the operations and behaviour of the expansion modules
installed on these devices.
Note - The current firmware version does not allow AT-View Plus Device Manager to support
the RPS LED.
Note - When connecting to a slave switch, AT-View Plus Device Manager does not
automatically replace the master switch image in the main window with the slave switch image.
The same is true when returning to the master switch from the slave switch. To view the updated
image, click on the Refresh option under the Agent menu.
Agent Menu
From the Agent menu, you can view and edit the system information for the device, or log into
the CLI using Telnet.
System Info
Displays basic system information, including system name, location, contact and
description.
Note - The current firmware version allows the user to enter up to 38 characters for the
System Location parameter.
Note - Configuring the System Contact, System Name and System Location parameters
may sometimes result in the error message: "The error occurred with 'Set' operation.
Error: gen Error." However, the values are still set successfully.
Network Info
Displays network-related information such as the addresses of the default gateway and the
agents.
Device Info
Displays general information about the switch.
PN 613-50665-00 Rev C Page 144 of 294
