Allied Telesyn AT-VIEW PLUS
DEVICE MANAGEMENT
AT-MCM1000S Modules
MCM1000S
LED State Description
RAD Green The LX port is connected to a remote access device.
Note - The TP Link Status parameter reflects the status of the SX port while the F/O Link Status
parameter reflects the status of the LX port.
Note - The remote access device connected to the LX port may at times be inaccessible when
link is established on the SX port. As a result, the RAD LED may turn gray and the following
parameters may not return any value:
• Remote Device
• Remote Device Status
• Remote Device TP Link Status
PN 613-50665-00 Rev C Page 261 of 294
