Allied Telesyn AT-VIEW PLUS
DEVICE MANAGEMENT
Device Manager LEDs for AT-8624T/2M
LED State Description
PWR Green
Red
The switch is receiving power from the main power supply.
Main power supply is either off or has failed.
RPS Green
Red
Gray
The switch is receiving power from the redundant power supply.
RPS has failed.
RPS is not installed or RPS monitoring is disabled.
DUPLEX Green
Orange
The port is operating at full duplex.
The port is operating at half duplex.
Note - The current firmware version does not allow AT-View Plus Device Manager to support
the Reset button.
Agent Menu
From the Agent menu, you can view and edit the system information for the switch, or log into
the CLI using Telnet.
System Info
Displays basic system information, including system name, location, contact and
description.
Power Supply Info
Displays information about the power supply, redundant power supply and power supply
monitoring.
File List
Displays a list of the files in the switch's file system.
Config File Name
Displays the file name of the start-up configuration file.
Telnet
Starts a Telnet connection to the switch.
WEB Browser
Opens your web browser and connects to the switch's HTTP server.
Note - The web browser can only contact the device if the device has a valid resource file
loaded and set, and the HTTP server and GUI on the device are enabled.
PN 613-50665-00 Rev C Page 163 of 294
