Allied Telesyn AT-VIEW PLUS
DEVICE MANAGEMENT
This document describes the operations and menus specific to particular Allied Telesyn models
of managed devices. For module-independent information, refer to the AT-View Plus Device
Manager User's Guide.
Basic Operations
AT-View Plus Device Manager's main window shows the main panel of the target device. It has
both common and device-specific menus on its menu bar.
Note - SNMPv3: All device-specific menu options are displayed regardless of the user's view
access security settings.
You can perform operations on the agent by doing a right click on the main panel or by selecting
a menu item from the menu bar. Ports and LEDs on the main panel indicate the status of the port,
system and traffic.
Topics:
• Common operations on the main window
• Menu for stacked devices
• Port selection dialog box
• Port status colors
• LED status
• Utilization
PN 613-50665-00 Rev C Page 11 of 294
