Allied Telesyn AT-VIEW PLUS
DEVICE MANAGEMENT
Device Manager LEDs for AT-MPB3000
LED State Description
PWR1 Green
Gray
Power supply 1 is installed and power is on.
Power supply 1 is not installed or it is installed but not powered on.
PWR2 Green
Gray
Power supply 2 is installed and power is on.
Power supply 2 is not installed or it is installed but not powered on.
RPS Green
Gray
The optional redundant power supply is installed and power is on.
The optional redundant power supply is not installed or it is installed
but not powered on.
Agent Menu
From the Agent Menu, you can view and edit the system information for the chassis, or log into
the CLI using Telnet.
System Info
Displays basic system information, including system name, location, contact and
description.
Note - AT-View Plus Device Manager allows the user to enter up to 112 characters for
the System Contact parameter, 132 characters for the System Name parameter, and 92
characters for the System Location parameter. However, entering more than 19 characters
for any one of these parameters may affect the values of the other two parameters.
Temperature Info
Displays the actual temperature of the chassis.
Power Info
Displays power supply status.
Telnet
Starts a Telnet connection to the chassis.
Status Menu
From the Status Menu, you can view information about AT-MPB3000 Modules installed on the
chassis. Options to view all/per module information are displayed.
AT-MPB3000
