Allied Telesyn AT-VIEW PLUS
DEVICE MANAGEMENT
Device Manager LEDs for AT-8300GB Series
LED State Description
PWR Green The switch is receiving power.
STACK ID Green The switch's position in the switch stack.
DUPLEX Green
Orange
The port is operating in full-duplex mode.
The port is operating in half-duplex mode.
Note - Status information for the gigabit ports will always be reflected on the RJ-45 gigabit port
images regardless of whether the gigabit ports have been set to operate as GBIC ports or as
Twisted Pair ports.
Note - When Global STP is enabled, the current firmware version sets the Port State parameter of
inactive ports to 'blocking'. As a result, expect port images for inactive ports to turn yellow in
AT-View Plus Device Manager.
Note - The current firmware version does not allow AT-View Plus Device Manager to detect the
presence or absence of a GBIC module in any of the GBIC slots. As a result, the GBIC slots on
the device image will remain empty regardless of whether or not GBIC modules are physically
present in the slots.
Agent Menu
From the Agent menu, you can view and edit the system information for the device, or log into
the CLI using Telnet.
System Info
Displays basic system information, including system name, location, contact and
description.
Note - The current firmware version does not allow multiple-word values for the System
Name parameter.
Note - AT-View Plus Device Manager allows the user to enter up to 255 characters for
the System Contact, System Name and System Location parameters but the current
firmware version truncates them to 64 characters.
Firmware Info
Displays the version of the software running on the managed device.
Network Info
Displays network-related information such as the device IP address and the default
gateway address.
Note - The current firmware version does not save changes made to the DNS Server and
the Default Domain Name parameters.
PN 613-50665-00 Rev C Page 58 of 294
