Allied Telesyn AT-VIEW PLUS
DEVICE MANAGEMENT
Note - The current firmware version allows active ports to be disabled. However, the
disabled ports' Port Link State parameter retains the value 'on-line'.
Note - Valid MIB Set values for the Port State parameter are 'enabled' and 'disabled'.
Attempting to set this parameter to any other value will result in the error message: "The
error occurred with 'Set' operation. Error: bad value."
Note - Attempting to configure the Port Speed and Mode parameter of an AT-
8216FXL/SC fixed port to '10Mbps half-duplex' or '10Mbps full-duplex' will
automatically set it to '100Mbps half-duplex' or '100Mbps full-duplex' respectively.
Note - The following parameters are not applicable to the AT-8200XL Series:
• Port Transmit Pacing Configuration
• Port MDI Configuration
• Port VDSL Rate Configuration
• Port VDSL Link Mode
Spanning Tree Info
Displays the port's spanning tree parameters.
Enable
Enables the port.
Disable
Disables the port.
Port Mirroring
Displays the information about port mirroring.
Expansion Module Notes
• When the Port Speed and Mode parameter of an AT-A14 expansion module port is set to
'auto sense' and the port is connected to a 100Mbps full duplex port on another device, its
corresponding Duplex LED on the device image turns orange instead of green.
• The current firmware version does not allow the Port Speed and Mode parameter of the
AT-A14 expansion module port to be set to any value other than 'auto-sense'.
• A GBIC image is always visible on the GBIC slot of the AT-A15 expansion module
image even if there is no GBIC physically present in the slot.
• The Port Speed and Mode parameter of an AT-A15 expansion module port must match
the duplex mode of the port to which it is connected in order to establish connection.
• The current firmware version does not allow AT-View Plus Device Manager to
distinguish the AT-A16, AT-A17, and AT-A19 expansion modules from each other. With
the connector type (VF-45, SC, MT-RJ) being the only difference among them, all three
expansion modules have been made to share the same GIF image.
• Attempting to configure the Port Speed and Mode parameter of an AT-A16/AT-A17/AT-
A19 expansion module port to '10Mbps half-duplex' or '10Mbps full-duplex' will
automatically set it to '100Mbps half-duplex' or '100Mbps full-duplex' respectively.
PN 613-50665-00 Rev C Page 41 of 294
