Chapter 5: Installing the Chassis on a Table or in an Equipment Rack
98
Figure 39. Rack Mounting Bracket Locations
Figure 40. Rack Bracket Locations for Reverse Position of Chassis
After adjusting the brackets, go to “Installing the Chassis in the Equipment
Rack” on page 99.
Factory Installed - Flush with Rack Rails
A B
C D E
“Dim X”
“Dim X” “Dim X” “Dim X”
Front panel facing
towards the rear
of the rack
F
