Chapter 9: Powering On the Chassis
172
Verifying the Installation
Please perform the following procedure before powering on the chassis:
1. Verify that the grounding lug on the back panel of the chassis is
properly grounded. For instructions, refer to “Installing the Chassis
Grounding Lug” on page 103.
2. Verify that all empty slots on the front panel of the chassis are covered
with slot covers. To cover open slots, perform the procedure “Installing
the Blank Slot Covers” on page 138.
3. Verify that dust plugs are installed in all empty SFP, SFP+, CSFP, and
XFP slots on the Ethernet line cards.
4. Verify that dust covers are installed on all SFP, SFP+, CSFP, and XFP
transceivers that do not have cables.
5. Verify that the chassis has at least one AT-SBx31CFC960 Controller
Fabric Card installed in slot 4 or 5.
6. Verify that the chassis has at least one AT-SBxPWRSYS1 Power
Supply in slot C or D.
7. If the chassis has AT-SBx31GP24 Line Cards, verify that it has at least
one AT-SBxPWRPOE1 Power Supply in slot A or B.
8. When you installed the AT-SBx31CFC960 Controller Fabric Card, did
you remove the battery insulator, shown in Figure 73 on page 130? If
not, remove the controller card from the chassis, remove the insulator
from the battery, and reinstall the card.
You may now power on the chassis. For instructions, refer to the
appropriate procedure:
 “Powering On the AT-SBxPWRSYS1 AC Power Supply” on page 173
 “Powering on the AT-SBxPWRPOE1 AC Power Supply” on page 176
 “Powering On the AT-SBxPWRSYS1 DC System Power Supply” on
page 179
Note
If the chassis has both AT-SBxPWRSYS1 and AT-SBxPWRPOE1
Power Supplies, you may power on the power supplies in any order
or simultaneously.
