SwitchBlade x3106 Chassis Switch and AT-SBx31CFC960 Card Installation Guide
93
Installing the Chassis in an Equipment Rack
The following sections contain the procedures for installing the unit in an
equipment rack:
 “Required Tools and Material” on page 93
 “Preparing the Equipment Rack” on page 93
 “Removing the Rubber Feet” on page 95
 “Adjusting the Equipment Rack Brackets” on page 96
 “Installing the Chassis in the Equipment Rack” on page 99
Required Tools
and Material
You need the following tools and material to install the product in an
equipment rack:
 #2 Phillips-head screwdriver
 Six equipment rack screws
 Flat-head screwdriver
 #2 Phillips-head 10 inch-lbs torque screwdriver (optional)
Warning
The chassis may be heavy and awkward to lift. Allied Telesis
recommends that you get assistance when mounting the chassis in
an equipment rack.
 E30
Preparing the
Equipment Rack
To prepare the equipment rack for the installation of the AT-SBx3106
Chassis, perform the following procedure:
Caution
The chassis is heavy and should be mounted as low as possible in
the equipment rack to maximize vertical stability.
1. Reserve 190.0 mm (7.5“) of vertical rack space for the installation of
the AT-SBx3106 Chassis, as shown in Figure 35 on page 94.
2. Do not mount any other equipment within 152.4 mm (6”) above this
space during installation. This additional vertical space is temporary
and allows you enough room to lift and tilt the chassis into its position
in the equipment rack without hitting other equipment, as shown in
Figure 41 on page 100. You may use this additional space for other
network equipment after the chassis is installed.
