Allied Telesis AT-SBx31CFC960 User Manual
Page 273
SwitchBlade x3106 Chassis Switch and AT-SBx31CFC960 Card Installation Guide
273
Figure 171. Loosening the Screw on the AT-SBxFAN06 Fan Module
6. Carefully pull on the handle to disconnect the fan module from the
connector on the backplane of the chassis. Refer to Figure 172.
Figure 172. Loosening the AT-SBxFAN06 Fan Module from the Backplane
Connector
