SBx Linecard Status LEDs
The SBx Linecard Status LEDs display general status information about
the controller and Ethernet line cards. There is one LED for each slot in the
chassis. If the chassis has two controller cards, the SBx Linecard Status
LEDs are active on both cards. The states of the LEDs are defined in
Table 19.
Table 19. SBx Linecard Status LEDs
LEDs State Description
0 to 11
Off Indicates that the slot is empty.
Solid Green Indicates that the controller or Ethernet line
card is operating normally.
Flashing Green Indicates that the card is booting up, in test
mode, or loading the configuration settings.
0 to 11
Solid Amber Indicates that the card is in an off-line,
reset, or disabled state. You may remove
the card from the chassis when it is in this
state. If the LED is solid amber for an
Ethernet line card, it may indicate that the
card cannot boot up because the controller
card does not have the appropriate load file
and needs to be updated to the most recent
release of management software.
Flashing Amber Indicates that the card is reporting a fault
condition. Use the management commands
to determine the specific problem.
