1000base-t connector pinouts – Allied Telesis AT-SBx31CFC960 User Manual
Page 287
SwitchBlade x3106 Chassis Switch and AT-SBx31CFC960 Card Installation Guide
287
Table 41 lists the pin signals when a 10/100/1000Base-T port is operating
at 1000 Mbps.
Table 41. 1000Base-T Connector Pinouts
Pin
Pair
Signal
1
1
TX and RX+
2
1
TX and RX-
3
2
TX and RX+
4
3
TX and RX+
5
3
TX and RX-
6
2
TX and RX-
7
4
TX and RX+
8
4
TX and RX-
