Chapter 8: Installing the Transceivers and Cabling the Ports
148
Note
The dust cover protects the fiber optic port on the SFP transceiver
from dust contamination. It should not be removed until you are
ready to connect the fiber optic cable.
6. Connect the fiber optic cable to the port on the transceiver, as shown
in Figure 90. The connector should snap into the port.
Figure 90. Attaching a Fiber Optic Cable to an SFP Transceiver in the AT-
SBx31GS24 Line Card
7. Repeat this procedure to install additional SFP transceivers.
After installing and cabling the SFP transceivers, do one of the following:
 To install and cable additional transceivers, go to the appropriate
section in this chapter for instructions.
 After cabling all the ports in the chassis, go to Chapter 9,
“Powering On the Chassis” on page 171.
