Allied Telesis AT-SBx31CFC960 User Manual
Page 144
Chapter 8: Installing the Transceivers and Cabling the Ports
144
Note
Patch cables for the AT-SBx31GT40 Line Card, in lengths of 1
meter and 3 meters with RJ point 5 and RJ-45 connectors, are
available from Allied Telesis. Contact your Allied Telesis sales
representative for information.
Figure 85. Connecting Cables to Ports on the AT-SBx31GT40 Line Card
Release Tab
Connecting a cable to a port
in the top row.
Connecting a cable to a port
in the bottom row.
