SwitchBlade x3106 Chassis Switch and AT-SBx31CFC960 Card Installation Guide

29

The LEDs on the AT-SBxPWRPOE1 AC Power Supply are described in
Table 3.

Table 2. LEDs on the AT-SBxPWRSYS1 DC Power Supply

LED

State

Description

DC
IN

Solid Green

The power supply is receiving DC power that is
within the normal operating range.

Off

The power supply is not receiving power from the
DC power source.

DC
OUT

Solid Green

The DC power that the module is providing to the
chassis components is within the normal
operating range.

Off

The power supply is not generating DC power or
the power is outside the normal operating range.

Fault

Solid Amber

The power supply has detected a fault condition,
such as an under-voltage, or over-temperature
condition.

Off

The power supply is operating normally or is
powered off.

Table 3. LEDs on the AT-SBxPWRPOE1 AC Power Supply

LED

State

Description

AC

Solid Green

The power supply is receiving AC power that is
within the normal operating range.

Off

The power supply is not receiving power from the
AC power source.

DC

Solid Green

The DC power provided by the module over the
backplane to the AT-SBx31GP24 PoE Line Cards
and the powered devices is within the normal
operating range.

Off

The power supply is not providing any DC power
or the power is not within the normal operating
range.

Fault

Solid Amber

The power supply has detected a fault condition,
such as an under-voltage or over-temperature
condition.

Off

The power supply is operating normally or is
powered off.
