Page 200
Chapter 9: Powering On the Chassis
200
Figure 146. Connecting the Positive Wire
6. Wrap the negative lead wire clockwise around the remaining terminal
screw and secure the screw and wire to the negative terminal
connection on the terminal block with a #3 Phillips-head screwdriver,
as shown in Figure 147 on page 201. The negative terminal is on the
right.
