5. Measurement pane
Shows the current values of channels under the cursor if the cursor is moved in the graph pane.
Moving the cursor over a text note icon shows the content of the text note in the pane.
If an overlay session is used, the overlay values are shown in parenthesis () and italics like this:
(overlay)
6. Graph Pane
Shows the graphs of the active channels color coded. Moving the cursor over a channel
highlights the channel (trace shown in double thickness). Right-clicking on the highlighted
channel brings up a menu to manipulate different aspects of the channel. Leaving the cursor on
the highlighted channel for a second will show the name of the channel.
7. Time scale area
Click with the + or – tool in the Time scale area to enlarge or reduce the time axis.
8. Note area
In this area notes can be placed to comment events at that point in the session. Notes are
indicated by an Icon . Moving the cursor over a note will show the note contents in the
Measurement Pane. Double-click on the note Icon to edit the note text. You can also move the
note in the note area by clicking and dragging.
Some MTS logging devices can record audio comments while logging. If an audio comment is
inserted, an audio note icon will be shown at the audio comment point. Double-click on the
icon to play the audio comment.
To delete a note, drag the note outside the note area.
9. Text Note
Indicates a text note at that point.
10. Measurement Marker
Any number of measurement Markers can be inserted in a graph. The measurement Markers
scroll with the graph. A measurement point shows the values of all active value channels at that
particular point in time.
11. Bit channel pane.
A bit channels is ON when the horizontal bar assigned to the channel is fat grey. It is off when it is
shown as a thin line.
12. Channel Markers
Each displayed channel has a set of 2 markers assigned to it. Only the markers of one channel
are shown at a time. The markers are a convenient way to see quickly if a channel value is below
or above a certain limit.
13. Session Tabs
Click on a tab to switch to the session represented by the tab.
14. Session length display.
Shows the total length of the session.
