5.6 Resetting and displaying Min/Max Value of a gauge
5.6.1 Resetting Min/Max hold
The current Min-Max recording of all gauges can be reset with either:
Gauges->Reset Min/Max
Or with the Tool in the Toolbar of the main Dash.
To reset the Min-Max of an individual gauge hold down the Ctrl key on your keyboard and click on
the gauge with the right mouse button.
5.6.2 Displaying Min/Max Values
Move the mouse cursor over a gauge. After a short delay the current Min/Max hold value the
gauge has stored will be shown.
5.7 Using multiple gauge sets
When recording many channels, for example with a large Log-Chain, it is often convenient to use
multiple gauge sets for different applications. Otherwise the window can get too crowded with too
many gauges. The Gauge Set Manager allows to store up to 16 different gauge sets.
A gauge set contains the size, position, type and channel assignment of all gauges on the
dash.
To store the current gauge set use the gauge set Manager.
Select in the Main Dashboard:
Gauges->Gauge Set Manager…
The gauge set manager window will appear:
