Innovate Motorsports ST-12 User Manual
St-12 supertune 12 engine data acquisition system
ST12_Manual_1.1.doc
ST-12
SuperTune 12 Engine Data Acquisition System
Warning!
The Oxygen Sensor used in this device gets very hot in operation. Do not touch the hot sensor.
Do not let a hot sensor touch a combustible surface. Do not use the sensor with or near
flammable liquids or gases. Failure to heed these warnings may result in severe burns,
explosions or fires.
When installed in the exhaust, the oxygen sensor MUST be connected and operating with the ST-
12 whenever the car is running. An un-powered oxygen sensor will be quickly damaged when
exposed to hot exhaust gases.
