Chapter 3 Installing Fans and Power Supplies
25
Determining Power Supply Status
When the amber power supply failure LED on the front of the chassis turns on,
determine which power supply is defective by checking the three status LEDs on
each supply. Each power supply has three LEDs that both indicate whether power
is supplied to the power supply and the health of the power supply. The LEDs are
ordered top to bottom on each power supply. Table 3-1 illustrates the states
indicated by the three LEDs.
Table 3-1. Power Supply LEDs
Power Supply Status PWR
(Green)
(Top
Position)
PFAIL
(Amber)
(Middle
Position)
FAIL
(Amber)
(Bottom
Position)
No AC power to any power supplies Off Off Off
No AC power to a specific power supply Off Off On
AC present / Standby output on Blinking Off Off
DC outputs on and okay On Off Off
Power supply failure Off Off On
Current limit On Off Blinking
Predictive failure On Blinking /
Latched
Off
Removing a Power Supply
To remove a power supply, complete the following procedure:
1. Locate the power supply you want to remove.
2. Push the thumb latch to unlock the power supply handle and pull the
handle down to undock the supply.
CAUTION Any unused power supply slots must be covered with a
blanking plug. Uncovered slots can disrupt the air flow used
for cooling the system.
