ADC Release 3.1 - Manual (Page 95)

1152700 • Issue 1 • February 2001 • Section 2 Operations and Maintenance
Page 2-75
© 2000, ADC Telecommunications, Inc.
DLP-706
Page 9 of 11
Cellworx Vision Information
Sucessfully configured the NE to begin software download for
the following slots: "16, 17"
X
OK
10934-C
Figure 706-11. Cellworx Vision Successful Software Image Download Message
Cellworx Vision
Both Ring Interface Cards in each of the network
elements have booted. You may now invoke
discovery to build the ring in the database and
create the graphical topology view.
X
OK
10935-B
Figure 706-12. Cellworx Vision NE Eligible for Discovery
Instructional Window
Cellworx Vision: Current Status
As each NE boots, configure the software load for that NE
by pressing and holding the right mouse button over the
corresponding line in the listbox.
Current status: Discovering network connectivity...
Cancel
X
Initiate Discovery
Network element ID: 1
Network element ID: 2
Network element ID: 3
NE discovered.
Discovering NE.
Rics have booted. NE eligible for discovery.
10914-C
Refresh
Figure 706-13. Cellworx Vision NE Current Status Window
