ADC Release 3.1 User Manual
Page 269

1152700
•
Issue 1
•
February 2001
•
Section 2 Operation and Maintenance
Page 2-249
© 2000, ADC Telecommunications, Inc.
DLP-754
Page 5 of 7
Table 754-2. T3 TMUX Multi 1 T1 Channel Configuration Options ,continued
SELECTION
DEFAULT
OPTIONS
DEFINITIONS
Facility Data Link
None
None
ANSI T1-403 FDL
A peer-to-peer protocol across a T1 line
providing OA&M functions (performance
monitoring, loop back etc.) implemented
via the framing bits in the T1 frame.
Circuit Identifier
Any alphanumeric
characters, up to 20?
User defined. Usually describes the traffic,
customer, and/or channel number.
Line Coding
AMI
AMI
Alternate Mark Inversion format. Not
selectable by user.
Table 754-3. ATM Interface Configuration Options for CRS Mode
SELECTION
DEFAULT
OPTIONS
DEFINITIONS
Interface Name
Alphanumeric
User defined, up to 20 alphanumeric
characters.
Loopback Location Code
All 1s
Alphanumeric
Used to loopback the incoming signal and
transmit it back to the customer equipment.
The code is limited to 16 numeric
characters.
Recording Interface ID
All 0s
Numeric
Identifies the site card and port location for
customer billing capabilities, (allows
assignment of a customer ID for each port.)
The code is limited to 15 numeric
characters.
Provisioned Endpoints
Displays how many VPC or VCC endpoints
are configured by administrator on this card.
Interface Type
UNI
UNI
NNI
Specifies interface type as User to Network
Interface or Network to Network Interface.
CAC Formula
PCR
PCR
SCR
Specifies Peak Cell Rate or Sustained Cell
Rate for Connection Admission Control.
Policing
Off
On or Off
User sets whether traffic will be policed for
Quality Of Service (QOS).
Cell Scrambling
Off
On or Off
User sets whether traffic will be scrambled.
Over Subscription Rate
User sets depending on traffic contract.
Max Active VPI Bits
0
0to 8
Sets the maximum number of bits that may
be utilized from this port.
Max Active VCI Bits
0
0 to 12
Sets the maximum number of bits that may
be utilized from this port.
Max number of VPCs
4096
0 to 256
Sets the maximum number of VPCs that
may be utilized from this port.
Max number of VCCs
0
0-8192
Sets the maximum number of VCCs that
may be utilized from this port.
