10. Slide the card in until the ejector ears reach the card cage trough. Fully seat the card into
the backplane by pressing the ejector ears toward the shelf until they rest against the
faceplate. Do not use excessive force. If excessive resistance is felt, remove the module,
check for alignment and/or obstructions, and try seating it again.
11. After replacing the card, the user may perform turn up of the NMIC per DLP-702.
Stop! You have completed this procedure.
Status
Active
APS
Timing
Port
1
622
Ring
622 RING SLOT 16 AND 17
Shelf
Manager
Status
Active
APS
Timing
Port
1
622
Ring
PCMCIA
ACO
RMT
Maj/Min
Critical
ACO
Active
Craft
Access
Enable
Status
Active
Source
Sync
Craft
Access
Shelf
Craft
Reset
1
6 1
7 1
8
10544-B
Figure 781-2. Example of Removing a Front Access Card
