DLP-721
Page 1 of 2
ABOUT NE
Summary: This procedure details the information displayed for an NE when the user selects it,
opens the pop-up menu, and chooses About.
1. Click and hold the right mouse button over the NE to open the NE pop-up menu window.
2. Select About located at the top of the pop-up window and release the mouse button.
Refer to
Figure 721-1 .
3. The Network Element About window appears displaying the NE name, number, software
version, the assigned vendor, the node alarm and power status, the current time, and the
total time the NE has been in service. Refer to
Figure 721-2 .
Stop! You have completed this procedure.
Cellworx Vision Subnetwork Management System
File Configuration Fault Performance Help
i
GNE-1
NE-2
NE-3
10942-F
Craft Interface...
Create Connection...
View Connection...
Configure Alarm Threshold...
About...
Reflash Boot Image
Configure Software...
Cellworx User: root
Local Time: 23:30 GMT Time: 23:30
Figure 721-1. NE Selection and Pop-up Menu Window
