Cellworx Vision: Add Leaf X
Connection Name: VP- Multicast
UNI/NNI: oc3cmm:S-14:P-1:L-atm:I-1
VPI: 5
Leaf Network Element: NE-3
Segment Endpoint Ingress NDC Egress NDC
Close Apply << Previous
Service Provider Profile
Remote Interface Identifier : 0
Remote Connection Identifier :
VPI: VCI: 0 0
Study Indication
Remote Interface Type:
UNI B-ICI FR UNI
DISPLAYS SELECTED
CONNECTION NAME.
SELECTED LEAF NE
SELECTED INTERFACE
CONFIGURED VPI
SET USAGE DATA OR
NETWORK DATA
COLLECTION.
SET FAR END LEC
IDENTIFICATION IF
DESIRED.
SET TO GENERATE USAGE
INFORMATION FOR STUDY
PURPOSES.
SET THE INTERFACE TYPE.
APPLY ALL CHANGES AND
ADD THE NEW LEAF ENDPOINT
TO THE CONNECTION. RETURN TO PREVIOUS
WINDOW TO CORRECT
OR CHANGE DATA. CLOSE WINDOW
WITHOUT SAVING
CHANGES.
14454-A
Figure 791-7. Add Leaf Window – Configure Endpoint
