Dlp-740, Page 4 of 5 – ADC Release 3.1 User Manual
Page 226
1152700
•
Issue 1
•
February 2001
•
Section 2 Operation and Maintenance
Page 2-206
2000, ADC Telecommunications, Inc.
DLP-740
Page 4 of 5
Cellworx Vision Subnetwork Management System
File Configuration
Fault Performance
Help
E
Cellworx NE
Unknown
Cellworx NE
Unknown
Cellworx NE
Unknown
ICON DIRECT SELECTION
TOOL ALLOWS DIRECT
SELECTION OF ANY ICON
IN THE WORK AREA FOR
DRAG AND PLACEMENT
POSITIONING.
11720-D
Cellworx User: root
Local Time: 23:30 GMT Time: 23:30
Figure 740-5. Cellworx Vision Redrawing ICON Layout
Cellworx Vision Subnetwork Management System
File Configuration Fault Performance
Software
NMIC Platform
Topology
Time and Date
Connection
10972-E
Refresh...
Remove Expansion Shelf Network Element
Remove Ring Network Element
Add Expansion Shelf Network Element
Add Ring Network Element
Force Network Discovery ...
Turn Up Ring...
Revert to Saved Icon Layout...
Ring Audit
Ring Upgrade
Figure 740-6. Cellworx Vision Revert to Saved Icon Layout Pull Down Menu
