SET SC CARD CONFIGURATION
Summary: This procedure details the steps required to set the SC card configurations utilizing
the Cellworx STN Phase 3.1 shelf level Graphical User Interface (GUI). User must have GUI
launched and accessed the chassis level GUI display per NTP-017 prior to performing this
procedure.
1. Double click on the SC card located in slot 1 in the shelf level GUI “Chassis View”at the
top of the window. Refer to Figure 748-1.
2. The SC card level display appears as shown in Figure 748-2. The Operational State of the
card should be “Up”, Availability shown as “Available”, and Protection state may be
“Enabled” or “Not Protected.” Use the small blocks on the configuration window to stretch
the view upward, enabling all parameters to be displayed.
3. The SC card IP address enables remote Telnet sessions via 10Base-T connection on the slot
18 EIM to the Shelf Controller. Set the IP address per work order or customer specifications
using dots between the sequences for the number values as shown in the following example:
ex., AAA.BBB.CCC.DDD
Where the - AAA = 0-255
BBB = 0-255
CCC = 0-255
DDD = 0-255
Note: This IP address will always connect the user to the active SC.
4. The craft port bit rate is not configurable and is shown here for display only. Step through
the remaining options and configure per system requirements. Refer to Table 748-1 for a list
of available parameters for each option.
5. Select the Apply button at the bottom of the window to send new parameters to the database.
6. Select the Close button at the bottom of the window to return to the Chassis View.
Stop! You have completed this procedure.
