ADC Release 3.1 - Manual (Page 156)

1152700 • Issue 1 • February 2001 • Section 2 Operation and Maintenance
Page 2-136

2000, ADC Telecommunications, Inc.
DLP-723
Page 4 of 5
Cellworx Vision Subnetwork Connection Configuration X
Connection Name :
Connection Type : ATM VP - ATM VP
Administrative State:
Locked
Unlocked
****************
Network Element: Node1
Segment Endpoint
Test Type:
Loopback Location ID:
Insert Loopback Cells:
Test Status: None
1111111111111111
Towards Acess Facility
No Test
Test Status Abort test
Network Element: Node2
UNI/NNI: Slot12_Port15 DS1CESUNI
Segment Endpoint
Test Type:
Loopback Location ID:
Insert Loopback Cells:
Test Status: None
1111111111111111
Towards Acess Facility
No Test
Test Status Abort test
Close Apply
Ingress NDC
Egress NDC
Ingress NDC
Egress NDC
VPI: 0
VPI: 0
UNI/NNI: Slot10_Port10 DS1CESUNI
Figure 723-4. Subnetwork Connection Configuration Window
