ADC Release 3.1 - Manual (Page 376)

1152700 • Issue 1 • February 2001 • Operation and Maintenance
Page 2-356
© 2000, ADC Telecommunications, Inc.
DLP-784
Page 7 of 7
Table 784-3. FE1 Frame Relay Interface Configuration Options, continued
SELECTION DEFAULT OPTIONS DEFINITIONS
Operational
Status Up Display Only Indicates the operational status of the interface.
Provisioned
Endpoints 0 Display Only Displays how many FR endpoints are configured
by administrator on this interface.
DLCI Length 2 Octets 10
Bits Display Only Indicates the size of the data link connection
identifier assigned to this interface.
Used Bandwidth Traffic
Dependant Display Only Indicates a percentage of Ingress and Egress
bandwidth utilized for the selected interface.
Effective
Bandwidth Traffic
Dependant Display Only Indicates a percentage
Interface Type UNI UNI
NNI User to Network Interface
Network to Network Interface
IWF Type FRF.5 FRF.5
FRF.8 Frame Relay Forum standards.
Frame Relay to ATM internetworking type.
Signaling
Protocol None None
LMI Rev 1
Annex D: ANSI-
T1.617D
Annex A: CCITT-
Q933A
Link Management Interface Protocol
