1152700 • Issue 1 • February 2001 • Section 2 Operation and Maintenance
Page 2-224
© 2000, ADC Telecommunications, Inc.
DLP-747
Page 4 of 5
Table 747-2. ATM Interface Configuration Options for CRS Mode
SELECTION DEFAULT OPTIONS DEFINITIONS
Policing Off On or Off User sets whether traffic will be policed for
Quality Of Service (QOS).
Cell Scrambling On On or Off User sets whether traffic will be scrambled.
Over Subscription Rate 100 100-1000 User sets percentage depending on traffic
contract.
Max Active VPI Bits 0 0-8 Sets the maximum number of bits allowed may
be utilized from this port.
Max Active VCI Bits 10 0 to 10 Sets the maximum number of bits allowed may
be utilized from this port.
Max number of VPCs 1 0 to 256 Sets the maximum number of VPCs that may
be utilized from this port.
Max number of VCCs 0 0 to 256 Sets the maximum number of VCCs that may
be utilized from this port.
Table 747-3. E1 Multi 1 Configuration Options for CES Mode
SELECTION DEFAULT OPTIONS DEFINITIONS
Interface Name Alphanumeric User defined, up to 20 alpha numeric characters.
ATM VPI defined> 0-8 This is a read only to show the available bits
configured for this port during connection creation.
ATM VCI defined> 0-10 This is a read only to show the available bits
configured for this port during connection creation.
Operational State Up Up/Down This is a read only to show the state of the port.
Buffer Maximum
Size 6220 5300 to 6220 Maximum size measured in microseconds and
selectable in 10 microsecond increments.
Cell Arrival Jitter
Tolerance 1040 950 to 2650 Maximum size measured in microseconds and
selectable in 10 microsecond increments.
CBR Clock Mode Adaptive Adaptive,
Synchronous,
or SRTS Sets the Constant Bit Rate clock to either adapt to
the incoming bit stream or look for a constant
synchronous bit stream.
