ADC Release 3.1 - Manual (Page 243)

1152700 • Issue 1 • February 2001 • Section 2 Operation and Maintenance
Page 2-223
© 2000, ADC Telecommunications, Inc.
DLP-747
Page 3 of 5
Table 747-1. E1 Multi 1 Configuration Options
SELECTION DEFAULT OPTIONS DEFINITIONS
Card and Port
Administrative State Unlocked Unlocked
Locked Enables or disables card or port for service,
respectively.
Ingress/Egress
Congestion
Threshold 80 0-100 Percentage of ingress or egress buffer capacity that
will cause a congestion threshold notification.
Ring Selection Auto Auto
Ring 16
Ring 17
Card will automatically select traffic from the ring
direction with the best signal.
Card will receive traffic from Ring 16 direction.
Card will receive traffic from Ring 17 direction.
Transmit Timing
Source Local Received
Local
Incoming clock pulse used for outgoing signal.
Clock pulse supplied by the SC cards used for
outgoing signal.
Service Type CRS CES
CRS Circuit Emulation Service.
Cell Relay Service.
Line Build Out 120 Ohms 75 Ohms
120 Ohms
Sets the signal strength according to the distance in
feet that the Cellworx STN is from the E1
interfacing equipment.
Line Coding HDB3 HDB3 European Standard, non configurable.
Line Type E1 CRC-4
MF E1 CRC-4
MF Sets the line type to reflect customer equipment.
Must be set in groups of 8 ports (1-8 and 9-16).
Loopback. Config None None
Terminal
Facility Line
No loopback activated on this card.
Sends cells to the cellbus and back to the ring. No
changes are made to the path layer data.
Loops the incoming signal back to CPE, generates
AIS to the cellbus.
Circuit Identifier Up to 20
alphanumeric
characters. User defined. Usually describes the traffic,
customer, and/or channel number.
Interface Name Alphanumeric User defined, up to 20 alpha numeric characters
Loopback Location
Code All 1s Alphanumeric Used to loopback the incoming signal and transmit
it back to the customer equipment, limited to 16
numeric characters.
Recording Interface
ID All 0s Numeric Identifies the site card and port location for
customer billing capabilities, (allows assignment of
a customer ID for each port), limited to 15 numeric
characters.
Provisioned
Endpoints 0 User cannot
configure. Displays how many VPC or VCC endpoints are
configured by administrator on this card.
Interface Type UNI UNI
NNI Specifies interface type as User to Network
Interface or Network to Network Interface.
CAC Formula PCR PCR
SCR Specifies Peak Cell Rate or Sustained Cell Rate for
Connection Admission Control.
(continued)
