Cellworx Vision: Add EPS NE - Reconnect Cables X
Cancelling at this time could leave the ring
in an abnormal state since the physical layout
has been modified. Please reconnect the
network elements back to the physical state
they were in prior to this procedure.
OK
10892-C
Figure 712-9. Add EPS NE - Reconnect Cables Instructional Window
Cellworx Vision: Configure Software - Network Elements
Apply
X
Clear Selected Continue >> Refresh
EE
Shelf Controller
OC-3c UNI MM/SC
Shelf Controller
2.0
scc.2.0.0.9
oc3mm.2.0.0.10
Card Type Slot Number (s) Selected Software Version
1
12
18
scc.2.0.0.9
Running Software Version Download Status
Config
11716-E
Press the right mouse button to display the available software images for each card.
Figure 712-10. Add EPS NE - Configure Software Load
