Cellworx Vision: Performance Monitoring Data NE 2
Card Type
Refresh All
X
155 MM CRS
Slot-Port Interval Suspect Supp ESs SESs CVs UASs FE ESs FE SESs FE CVs
S12-P2 00:00 - 00:15 0 0 0 0 0 0 0 0 900
Configure Thresholds Close Refresh
SONET Path SONET Line SONET Section
Only non-zero selected intervals are displayed.
13556-B
Reset Selected Clear Selected
Figure 726-2. Performance Monitoring Data – SONET Port Window
Cellworx Vision: PM Threshold Configuration SONET Path Layer
Card Type
X
622 Ring
Slot-Port ESs SESs CVs UASs FE ESs FE SESs FE CVs FE UAS
S17-P1
3 75 10 60 3 60 0 0
Close Apply
13552-B
Figure 726-3. 622 Ring Card SONET Path PM Threshold Configuration Screen
Table 726-1. SONET PM Values
MONITOR
TYPE
MAX 15-MIN
THRESHOLD COMMENTS
SECTION
CV 16383 Code Violation, a count of Bit Interleaved Parity (BIP) errors detected at the Section
layer using the B1 byte in the incoming SONET signal
ES 900 Errored Seconds, number of seconds in which at least one Section layer Bit
Interleaved Parity (BIP), Loss Of Signal (LOS), or Severely Errored Frame (SEF)
was detected
SEFS 900 Severely Errored Frame Seconds, a count of seconds that four consecutive incoming
section frames are errored
SES 900 Severely Errored Seconds, a count of seconds in which a set number of Section BIP
errors, LOS, or SEF were detected
(continued)
