Section 2 Operation and Maintenance

Page 2-157

2000, ADC Telecommunications, Inc.

DLP-729

Page 3 of 4

Cellworx Vision: PM Threshold Configuration AAL1 Layer

Card Type

X

T1 MULTI

Slot-Port

ESs

SESs

SEFSs

UASs

CSS

S4-P1

0

0

0

0

0

Close

Apply

13563-B

Figure 729-3. Performance Monitoring T1 Multi Port Configuration Window

Table 729-1. T1 Multi 1 CRS Performance Monitoring Values

MONTYPE

MAX 15 MIN.
THRESHOLD

COMMENTS

CV-L

16383

Sets a count of line code violations that the port can incur before creating a
TCA on the system. Line code violation is a count of *BPVs and *ExZs.

ES-L

900

Sets a count of line errored seconds that the port can incur before creating a
TCA on the system. ES-L is determined as number of seconds that BPV and
ExZ >=1 or LOS (loss of Signal) >=1.

SES

900

Sets a count of line severely errored seconds that the port can incur before
creating a TCA on the system. SES is determined as the number of seconds
CV-L >=1547 or LOS (Loss of Signal) >=1.

CV-P

16383

Sets a count of path code violations that the port can incur before creating a
TCA on the system. CV-P determined from SF count of FE, or ESF count of
CRC errors.

UAS

900

Sets a count of unavailable seconds that the port can incur before creating a
TCA on the system. UAS determined as the number of seconds that the path is
unavailable.

BES

900

Sets a count of Burst Errored Seconds that the port can incur before creating a
TCA on the system.

CSS

900

Sets a count of Controlled Slip Seconds that the port can incur before
creating a TCA on the system. CSS is determined as a count of 1 second
intervals where CS >=1.

SEFS

900

Sets a count of severely errored frame seconds that the port can incur before
creating a TCA on the system. SEFS determined when SEF >=1.

DM

2

Sets a count of minutes that the port can incur a signal degradation before
creating a TCA on the system.

ES

900

Sets a count of errored seconds that the port can incur before creating a TCA
on the system. Error seconds determined as number of seconds FE>=1, SEF
>=1, or any Cellworx Vision/AIS condition.

(continued)
