ADC Release 3.1 - Manual (Page 68)

1152700 • Issue 1 • February 2001 • Section 2 Operations and Maintenance
Page 2-48
© 2000, ADC Telecommunications, Inc.
DLP-701
Page 3 of 10
RECEIVE FIBERS FROM ONE DIRECTION.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
FIBERS FROM SLOT 13 ARE ROUTED
THROUGH THE UPPER ROUTING
FLANGES AT SLOT 14.
FIBERS DESTINED FOR SLOT 13
DROP THROUGH THE UPPER
ROUTING FLANGES AT SLOT 12.
TRANSMIT FIBERS IN ONE DIRECTION
10716-C
Figure 701-2. Routing Fiber Across the Fiber Management Panel
SLOT 16
SLOT 17
TX RX
TX RX
NODE 3
SLOT 16 SLOT 17
TX
RX TX
RX
NODE 4
SLOT 16
SLOT 17
TX RX
TX RX
NODE 1
SLOT 16 SLOT 17
TX
RX TX
RX
NODE 2
12385-A
Figure 701-3. 622 RIC Fibering Convention
