ADC Release 3.1 - Manual (Page 105)

1152700 • Issue 1 • February 2001 • Section 2 Operations and Maintenance
Page 2-85
© 2000, ADC Telecommunications, Inc.
DLP-708
Page 5 of 7
Cellworx Vision: Connection Configuration X
Connection Name:
Connection Type: ATM VC - ATM VC
NE-1 <--> NE-2
Next >> Close
Locked
Unlocked
NE-1
NE-2
NE-3
Slot / Card Type:
Administrative State:
Network Element: NE-2
Network Interface / Interface Type:
10907-C
ASSIGN A CONNECTION NAME
SELECT A CONNECTION
TYPE: VC,VP, FR, OR CES
SELECT AN NE FROM
AVAILABLE LIST FOR
ORIGINATING CONNECTION
POINT.
SELECT AN NE FROM
AVAILABLE LIST FOR
DESTINATION CONNECTION
POINT.
THE SLOT / CARD TYPE ARE
THEN DISPLAYED FOR
SELECTION HERE.
SELECT THE NETWORK
INTERFACE CARD AND
PORT FROM AVAILABLE
LIST FOR THE ORIGINATING
CONNECTION ENDPOINT.
USE SLIDER BARS TO VIEW
MORE INTERFACES.
Network Element: NE-1
Slot 11_Port 2 Oc3SM / UNI
Slot 12_Port 1 Oc3SM / UNI
Slot 12_Port 2 Oc3SM / UNI
Slot 13_Port 1 T3 TMUX
NE-1
NE-2
NE-3
Slot / Card Type: Network Interface / Interface Type:
Please select an endpoint 1 network element.
Endpoint 1
Endpoint 2
SELECT THE NETWORK
INTERFACE CARD AND
PORT FROM AVAILABLE
LIST FOR THE DESTINATION
CONNECTION ENDPOINT.
Slot 9_Port 1 DS3 / UNI
Slot 9_Port 2 DS3 / UNI
Slot 9_Port 3 DS3 / UNI
Slot 16_Port 1 Oc3MM / UNI
Slot 16_Port 2 Oc3MM / UNI
Slot 10_Port 1 Oc3SM / UNI
Slot 10_Port 2 Oc3SM / UNI
Slot 11_Port 1 Oc3SM / UNI
Slot 11_Port 2 Oc3SM / UNI
Slot 12_Port 1 Oc3SM / UNI
Slot 12_Port 2 Oc3SM / UNI
Slot 3_Port 1 DS3 / UNI
Slot 3_Port 2 DS3 / UNI
Slot 3_Port 3 DS3 / UNI
Slot 13_Port 1 Oc3SM / UNI
Slot 13_Port 2 Oc3SM / UNI
9 T3 CRS
11 155 SM CRS
12 155 SM CRS
13 T3 TMUX
16 155 SM CRS
3 T3 CRS
5 155 SM CRS
6 155 SM CRS
7 T3 TMUX
10 155 SM CRS
4 T3 CRS
11 155 SM CRS
12 155 SM CRS
13 155 SM CRS
Slot 11_Port 1 Oc3SM / UNI
Figure 708-3. Cellworx Vision ATM Virtual Connection Configuration Window
