Dlp-703, Page 2 of 2, Figure 703-2. remote craft logon screen – ADC Release 3.1 User Manual
Page 82
1152700
•
Issue 1
•
February 2001
•
Section 2 Operations and Maintenance
Page 2-62
© 2000, ADC Telecommunications, Inc.
DLP-703
Page 2 of 2
X
ID
: User Defined
: User Defined
Location
Welcome to ADC-BBG: Cellworx Shelf Interface Version 0.0.1
(C) Copyright 1998-99 ADC Telecommunications, INC.
Username: cellworx
Password:
********
Press CONTROL-R to Refresh
Time: 14:45
10644-C
User: cellworx
Figure 703-2. Remote Craft Logon Screen
X
ID
: User Defined
: User Defined
Location
Welcome to ADC-BBG: Cellworx Shelf Interface Version SCC.1.2.0.xx
(C) Copyright 1998-99 ADC Telecommunications, INC.
Press CONTROL-A For Assistance
Time: 14:45
CELLWORX MAIN MENU
1. System Configuration
2. Alarms
3. Card and Interface Configuration
4. Display Status
5. Performance Monitoring
6. System Maintenance
7. System Administration
8. Login To Remote Network Element
10607-F
User: cellworx
Active SCC Slot: 1
Figure 703-3. Cellworx STN Node Craft Screen Main Menu
