10. To configure the thresholds, place the cursor in the individual count boxes and type in the
new threshold value. Refer to Table 730-1 for valid values. Once all counts are entered in
each box, select the Apply button at the bottom of the screen to send the new data to the
database.
Stop! You have completed this procedure.
Cellworx Vision: Performance Monitoring Selection Criteria
Close
X
Resource:
NE 1: Cellworx1
NE 2: Cellworx2
NE 4: CellworxEXP
Port Layer Interval
current
00:00 - 00:15
00:15 - 00:30
00:30 - 00:45
01:45 - 02:00
01:00 - 01:15
01:30 - 01:45
01:15 - 01:30
00:45 - 01:00
02:00 - 02:15
Apply
Slot / Card Type
Slot 7 / T3 CRS
Slot 6 / Port 1
-- Slot 6 / Port 1 / Ch
NE 3: Cellworx3
Slot 10 / T3 CRS
ATM/TC
Slot 4 / T1 MULTI 1
Slot 5 / T1 MULTI 1
Slot 6 / T3 TMUX MUL
Slot 12 / 155 MM CRS
Slot 16 / 622 Ring
Slot 17 / 622 Ring
DS1
AAL1
-- Slot 6 / Port 1 / Ch
-- Slot 6 / Port 1 / Ch
-- Slot 6 / Port 1 / Ch
-- Slot 6 / Port 1 / Ch
-- Slot 6 / Port 1 / Ch
-- Slot 6 / Port 1 / Ch
-- Slot 6 / Port 1 / Ch
-- Slot 6 / Port 1 / Ch
13566-B
Figure 727-1. Performance Monitoring Selection Criteria Screen (example)
Cellworx Vision: Performance Monitoring Data NE 2
Card Type
X
T1 Multi 1
Slot-Port Interval ESs SESs SEFSs UASs CSSs PCVs LESs
S10-P1-C1 current 0 0 0 0 0 0 0 0 900
DS1
Only non-zero selected intervals are displayed.
13555-C
Refresh All Configure Thresholds Close Refresh Reset Selected Clear Selected
BESs DMs
Figure 727-2. Performance Monitoring Data – T3 TMUX Multi 1 Port (example)
Cellworx Vision: PM Threshold Configuration AAL 1 Layer
Card Type
X
T3 TMUX Multi 1
Slot-Port ESs SESs SEFSs
S6-P1-C1
Close Apply
0 0 0 0
UASs CSSs PCVs
13568-B
Figure 727-3. Performance Monitoring Configuration – T3 TMUX Multi 1 Port (example)
