1152700 • Issue 1 • February 2001 • Operation and Maintenance
Page 2-382
© 2000, ADC Telecommunications, Inc.
DLP-787
Page 9 of 12
Table 787-2. User Selectable Service Class Types and Parameters
SERVICE CLASS TYPE SELECTABLE PARAMETERS COMMENTS
ATM CBR, QoS Class I Peak Cell Rate (PCR) Kbps
Cell Loss Priority (CLP) = 0 + 1
Card type and contract dependent.
QoS Class I defined, not selectable.
ATM VBR, QoS Class II Peak Cell Rate (PCR) Kbps
Sustained cell rate (SCR)
Cell Loss Priority (CLP)
Tagging
Maximum Burst Size (MBS)
Card type and contract dependent, CLP always
equals 0+1.
Card type and contract dependent.
Determines if SCR connection is a VBR.1
(CLP=0+1) or VBR.2 (CLP=0).
Determines if SCR connection is a VBR.2 (No)
or VBR.3 (Yes).
Predetermined selectable values of 32, 50, 100,
150, or 210. See note below.
ATM UBR, QoS Class
Unspecified None No Selectable Parameters for UBR service.
Cell Delay Variation
Tolerance Specified in microseconds User defined according to traffic contract.
Cellworx Vision Subnetwork Management System
File Configuration Fault Performance
Software
NMIC Platform
Topology
Time and Date
Create...
View Fiber Bandwidth Usage ...
View Ring Resource Usage ...
Configure Service Provider Profile ...
Configure Traffic Contract ...
View ...
Connection
10963-D
Figure 787-7. GUI Connection Menu Tree
