Table 755-3. Configuration Options for CES Mode
SELECTION DEFAULT OPTIONS DEFINITIONS
Interface Name Alphanumeric User defined, up to 20 alpha numeric characters.
ATM VPI defined> 0-8 This is a read only to show the available bits
configured for this port during connection creation.
ATM VCI defined> 0-10 This is a read only to show the available bits
configured for this port during connection creation.
Operational State Up Up/Down This is a read only to show the state of the port.
Buffer Maximum
Size 5300 to 6220 Maximum size measured in microseconds and
selectable in 10 microsecond increments.
Cell Arrival Jitter
Tolerance 950 to 2650 Maximum size measured in microseconds and
selectable in 10 microsecond increments.
CBR Clock Mode Adaptive or
Synchronous Sets the Constant Bit Rate clock to either adapt to
the incoming bit stream or look for a constant
synchronous bit stream.
Cellworx Vision: ATM Interface
Apply Card View Refresh Close
X
Node Name: Cellworx1
Node Id: 1
Location: 5th Street
Slot Number: 8
Card : T1 MULTI 1
Port Number: 1
Interface Name: Slot8_Port1 DS1CESUNI
Loopback Location Code:
Recording Interface ID:
1111111111111111
0000000000000000
Provisioned Endpoints:
Number of VPCs: 0
Number of VCCs: 0
Interface Type: CAC Formula:
UNI
NNI
PCR Based
SCR Based
Policing
Cell Scrambling
Over Subscription Rate (%): (100-10 100
VP/VC Allocation:
Max Active VPI Bits:
0
0 1 2 3 4 5 6 7 8
Max Active VCI Bits:
1
0 1 2 3 4 5 6 7 8 9 1
Max Number of VPCs:
Max Number of VCCs:
(1-1)
(0-256)
Error Log:
13431-A
Cellworx Vision: CES Interface
Apply Card View Refresh Close
X
Node Name: Cellworx1
Node Id: 1
Location: 5th Street
Slot Number: 6
Card : E1 MULTI 1
Channel Number: 1
Interface Name: Slot8_Port1 DS1CESUNI
Up
CBR Clock Mode
Adaptive
Synchronous
microsecon 6220
ATM VPI:
ATM VCI:
Operational State:
Buffer Maximum Size:
Cell Arrival Jitter Tolerance: microsecon 1040
1
32
14547-A
Figure 755-2. T1 Multi 1 ATM Interface Options Figure 755-3. CES Interface Menu Options
