1152700 • Issue 1 • February 2001 • Section 2 Operation and Maintenance
Page 2-108

2000, ADC Telecommunications, Inc.
DLP-713
Page 2 of 5
10. The fourth section of the window lists generic troubles that are available for alarm retrieval.
Select the desired generic troubles for the alarm report either one at a time, each followed
with the >> button, or all of them by selecting the ALL>> button. For a complete listing of
alarms, refer to Section 4, Troubleshooting Guidelines.
11. Once the alarm filter has been customized to retrieve the alarms desired, select the Apply
button to save the changes or select Close to abort any changes and close the screen.
12. The selected alarms for the 15-minute time specified in the Interval (GMT) dialog box are
displayed in chronological order under the Filtered Traps section of the window. Refer to
Figure 713-2. For a list of GUI alarms and troubleshooting tips, refer to the TAP section of
this document.
Stop! You have completed this procedure.
Cellworx Vision Subnetwork Management System
File Configuration Fault Performance
E
Alarms
NMIC Protection Restoration
NMIC Protection
Configure NE Alarm Threshold...
10916-D
Figure 713-1. Cellworx Vision Fault Pull Down Menu
