Parameter
Setting value / Description / Note
Available with option
P733
Phase V current
always visible
0.0 ... 500.0 A
Displays the actual V phase current.
Note: This value can, due to the measurement procedure used even with symmetrical output currents,
deviate somewhat from the value in P719.
P734
Phase W current
always visible
0.0 ... 500.0 A
Displays the actual W phase current.
Note: This value can, due to the measurement procedure used even with symmetrical output currents,
deviate somewhat from the value in P719.
P735
Speed encoder
ENC POS
-9999 ... +9999 rpm
Displays the actual speed supplied by the encoder.
P736
DC link voltage
always visible
0 ... 1000 V
Displays the actual link voltage.
P740
... - 01
...
... - 06
PZD Bus In
always visible
0 ... FFFF hex
Displays the actual control word and the setpoints.
... - 01 = Control Word
... - 02 = Setpoint 1 (P546)
... - 03 = Setpoint 1 Highbyte
... - 04 = Setpoint 2 (P547)
... - 05 = Setpoint 3 (P548)
... - 06 = Bus I/O In Bits (P480)
P741
... - 01
...
... - 06
PZD Bus Out
always visible
0 ... FFFF hex
Displays the actual status word and actual values.
... - 01 = Status Word
... - 02 = Actual value 1 (P543)
... - 03 = Actual value 1 Highbyte
... - 04 = Actual value 2 (P544)
... - 05 = Actual value 3 (P545)
... - 06 = Bus I/O In Bits (P481)
P742
Database version
always visible
0 ... 9999
Displays the internal database version of the frequency inverter.
P743
Inverter ID
always visible
0.00 ... 250.00
Displays the inverter power in kW, e.g. "15"
FI with 15 kW nominal power.
P744
Configuration
always visible
0 ... 9999
The option modules recognised by the frequency inverter are displayed in this parameter.
The display with the ParameterBox is in plain text.
The possible combinations are displayed in code in the ControlBox. The Customer Units in use are
displayed on the right. If another Encoder module is installed, this is indicated in the second digit with a
1, the option PosiCon is indicated with a 2.
Customer Unit SK CU1-
…
Special Extension Unit SK XU1-...
No IO
XX00
Basic IO
XX01
Standard IO
XX02
Multi IO
XX03
USS IO
XX04
CAN IO
XX05
Profibus IO
XX06
Encoder
01XX
PosiCon
02XX
