EZwarePlus Programming Manual

67

Build Download Data for SD/USB Disk

Data can be downloaded to the HMI5000P Series using an SD card and USB flash drive. The Build Download

Data function builds the data files to do this.

To build download data for SD card or USB flash drive:

1. Start Utility Manager.

2. Click Build Download Data for SD/USB Disk… The Utility Manager dialog appears.

3. Insert SD card or USB flash drive into PC. Note the drive that represents the SD/USB device.

4. Click Browse... next to Select the folder to save download data: to select the drive that represents

the SD/USB device.

5. Check the boxes that will be the sources for your data and browse to the appropriate file for that

source. Click Build.

The L Series do not support SD cards.

Download

Sends a compiled project file stored on the computer to the HMI.

Upload

Receives a compiled project file from the HMI to be stored on the computer.

Simulation Settings

On-line Simulation

Opens a compiled project (*.xob) in on-line simulator mode.

Off-line Simulation

Opens a compiled project (*.xob) in off-line simulator mode.

1010-1015, Rev. 03
