EZwarePlus Programming Manual

65

b. Save file as *.emi for extended memory files.

You must use file names which correspond to the ten extended memory areas

preconfigured in the HMI (ex. em0.emi, em1.emi, …, em9.emi).

c. Save file as *.csv to open the file in applications such as Microsoft Excel.

8. Once the file is saved, you can copy the recipe file to your HMI by:

a. Procedure 1-- Downloading the file using the Utility Manager:

i. With the computer connected to your HMI, click Download.

ii. On the Download dialog box, check the RW enable box, then select the recipe file.

b. Procedure 2 -- Downloading using a SD card or USB Flash Drive:

i. Attach an SD card or USB Flash Drive to your computer.

ii. In Project Manager, click Build Download Data for SD/USB Disk button.

iii. Select the folder to save download data. Enter the SD card or USB Flash drive

location.

1010-1015, Rev. 03
