222

EZwarePlus Programming Manual

1. Check the Enable Operation Log Function checkbox. The object list displays all objects available for

recording in the Operation log. Use the filter button

to select the type of object(s) that appear in the list.

2. Check the Enable box for each object to be recorded. Click the Select All / Discard All buttons to select or

deselect all objects shown in the list.

3. Use the Storage Settings section to determine how much data is stored in HMI internal memory, and when

to archive data to an SD or USB device.

Maximum Record No. in HMI Memory

Select the maximum number of records to store in

HMI memory. This memory is shared with Data

Sampling and Alarm/Event logging. This is not the

maximum amount of data to log.

External Devices for Synchronization/Backup

Select whether to archive to an SD or USB device.

Behavior when HMI Space is Insufficient

• Stop Saving Operation Log: No more data is saved,

and no archiving is done.

• Synchronize to External Device: The data is

archived to the SD or USB device. If previous data

exists on the SD/USB device, the new data is

merged with the existing data. If there is sufficient

storage space in the HMI, half of the data in the

log is erased to make room for more data. If there

is insufficient storage space in the HMI, all of the

data in the log is erased.

Note: If the specified SD or USB device does not

exist, old data is erased from the log to make

room for new data.

Control Address

Specifies the first of two addresses that allow

commands to be sent to the Operation Log:

[Specified Address] : Command

1 – Clear all records

2 – Copy all records to the USB device

3 - Copy all records to the SD device.

4 - Copy all records to the USB device, and clear all

records from the log.

5 - Copy all records to the SD device, and clear all

records from the log.

[Specified Address + 1] : Command

0 – Processing the command

1 – Command Successful

2- The device does not exist

3 -The records does not exist

4 – Unknown error.

1010-1015, Rev. 03
