Using the Developer
AnaWin User’s Guide 10-5
Adding an Object
To add an object, click the corresponding add button at the top of the
screen, shown below in Figure 10-4. Then set the properties for that object
as described below under “Setting Object Properties.”
FIGURE 10-4 Add Toolbar Buttons
Deleting an Object
To delete an object, select the object by clicking on it, then press the
backspace key.
Copying an Object
To copy an object, select the object by clicking on it, then click the
corresponding add button. Note that some properties—such as
position—do not copy.
NOTE
Whenever you select an object, its type is displayed in the message
box at the bottom left of the screen.
Modifying an Object
To modify an object, select the object by clicking on it, then edit the
parameters as described below under “Setting Object Properties.”
Moving an Object
To move an object, hold the Shift key while clicking and dragging the
object.
• If you are moving a single object, release the mouse button first, then
the Shift key when the object is in the desired position. This takes
you out of move mode.
• If you are moving multiple objects, release the Shift key first, then
the mouse button. This keeps you in move mode, and you can then
click and drag additional objects. To get out of move mode, press
and release the Shift key.
Add Label Add Graphic Add Digital I/O Text Add Animation
Add Field Add User Variable Add Digital I/O Image Add Zoom
