6-2 AnaWin User’s Guide
Managing Recipes
NOTE
If you have enabled channel grouping, you will choose a group to
work with immediately after selecting New, Open, Remove, or
Download from the Recipe menu. Separate sets of recipes are main-
tained for each group.
New
Select New to display the Recipe Editor screen, shown in Figure 6-1. From
this screen, you can create new recipes based on an existing recipe.
When you select New, the grid on the Recipe Editor screen is filled with
the current controller values.
FIGURE 6-1 Recipe Editor Screen
Recipe Spread Sheet
The Recipe Editor screen includes a spread sheet that allows you to
create a recipe. The parameters in the spreadsheet vary, depending on
the controller. Refer to your controller manual for information about the
various parameters.
To create a recipe using the spreadsheet, enter the desired operating
parameters by double-clicking a cell with a numeric value and typing a
new value or by using the pull-down selection boxes. Use the scroll bars
to access parameters (columns) and channels (rows) beyond the borders
of the Recipe Editor screen. You can also use the normal Windows
editing keys: cut (Ctrl-X), copy (Ctrl-C), and paste (Ctrl-V).
NOTE
Editing recipe parameters has no effect on the controller(s) until the
recipe is downloaded.
